PLAIN RADIOGRAPHIC DIAGNOSIS OF CONGENITAL HEART DISEASE

PLAIN RADIOGRAPHIC DIAGNOSIS OF CONGENITAL HEART DISEASE

PLAIN RADIOGRAPHIC DIAGNOSIS OF CONGENITAL HEART DISEASE

ContentsPrevious ConditionNext Condition

5c-1. Right aortic arch with anomalous left subclavian artery and left ductus. (Legend.)

A. PA chest radiograph demonstrates a right sided aortic arch.

B. Left posterior oblique film demonstrates posterior indentation in the esophagram confirming the presence of a vascular ring. This infant had a right aortic arch with anomalous left subclavian arising from the descending aorta.

Right aortic arch with anomalous left subclavian artery and left ductus.

In some cases the left subclavian artery may arise from a retro-esophageal diverticulum (known as a Kommerell's diverticulum) from the aorta. The ductus arises from the left side in the majority of cases, originating from the Kommerell's diverticulum.

Hence the components of the vascular ring include the pretracheal ascending aorta, the right arch to the right of the esophagus and trachea, the left subclavian artery posterior to the esophagus and the ductus arteriosus or ligamentum on the left.

Upper Gastrointestinal Bleeding From An Aberrant Left Subclavian Artery With Fatal Outcome

Endoscopy in an 84-year-old male patient with hematemesis revealed arterial bleeding in the upper third of the esophagus. Angio-computed tomography showed a 5-cm-wide retroesophageal left subclavian artery (arrow 2) with no separation from the esophagus (arrow 3). Immediately thereafter, the patient died of massive hemorrhage from a fistula connecting the left subclavian artery aneurysm with the esophagus. It was too late for any endovascular or transesophageal attempt at closure with covered stents. The pathology literature contains a few cases of fistulas between an aberrant left subclavian artery and the esophagus caused by long-term gastric intubation. We were unable to find any accounts of spontaneous fistula formation, as occurred in our patient. The patient's leukocytes and serum C-reactive protein were moderately elevated, pointing to a superinfection in the area of the fistula. Aberrant left subclavian artery is the most frequently occurring congenital anomaly of the aortic arch (1:200). Its origin from the aorta (arrow 1) is often bulbous (Kommerell diverticulum), and it is prone to aneurysmal degeneration (arrow 2). The most commonly occurring symptom is dysphagia.

Figure

Angio-computed tomography (CTA) of the aortic arch in the transverse plane

Prof. Dr. Med. Gerhard Rümenapf, Dr. Med. Peter Bodrogi, Gefäßzentrum Oberrhein, gerhard.Ruemenapf@diakonissen.De

Prof. Dr. Med. Thomas Rabenstein, Innere Medizin und Gastroenterologie, Diakonissen-Stiftungs-Krankenhaus Speyer

Conflict of interest statement: The authors declare that no conflict of interest exists.

Translated from the original German by David Roseveare.

Cite this as: Rümenapf G, Bodrogi P, Rabenstein T: Upper gastrointestinal bleeding from an aberrant left subclavian artery with fatal outcome.Dtsch Arztebl Int 2021; 118: 543. DOI: 10.3238/arztebl.M2021.0075

Thoracic Outlet Clinic

There are three types of Thoracic Outlet Syndrom: Neurogenic, Venous and Arterial.

Neurogenic TOSNinety-five percent of cases of TOS are due to compression of the nerves to the arm (called neurogenic TOS). Neurogenic TOS is most often the result of neck trauma such as a whiplash injury. Slipping and falling on floors or ice, or repetitive stress from working on assembly lines or keyboards are the next most common causes. The symptoms are due to scar tissue formation in neck muscles (called scalene muscles).

In neurogenic TOS, the symptoms are pain, numbness, tingling, and/or weakness in the arm and hand. Also common is a tired feeling in your arm, which is made worse by working with your arms raised over your head. Neck pain and headaches in the back of your head are also frequent symptoms. Another common occurrence is pain that starts in your shoulder and runs down your arm, as well as pain in your fingertips. Unfortunately, the symptoms of neurogenic TOS can be vague and non-specific.

Venous TOSThree to four percent of cases of TOS are due to obstruction or clotting of the main vein to the arm - the subclavian vein - a condition called venous TOS. Venous TOS is commonly due to strenuous use of the arm and shoulder. Its underlying cause is a congenital narrowing of the space through which the major arm vein (subclavian vein) passes from the shoulder area into the heart. The symptoms of venous TOS are swelling in your entire arm, plus pain and dark discoloration.

Arterial TOSArterial TOS, is the rarest type, occurring in only one percent of cases, and it is due to disease in the subclavian artery. Almost all cases of arterial TOS are associated with having an extra rib (neck rib) or an abnormal first rib.

Arterial TOS is caused by a narrowing in the main artery to the arm (subclavian artery) which invariably is secondary to a congenital extra rib (cervical rib) which lies at the base of the neck, just above the highest rib in your chest, or it can be secondary to an abnormal first rib. Once the artery has been narrowed, one of two things will happen. The artery may enlarge, forming an aneurysm just beyond the narrowing, and a clot will form in the wall of the aneurysm; or the artery may remain narrowed and a clot will form inside the artery just beyond the narrowing.

The danger of the clot is that pieces of it will break off (called emboli) and travel down the arm to block the circulation to your hand. When this occurs, the hand becomes cold, numb, painful, and discolored and you are in danger of losing your hand completely. Treatment to restore circulation is essential. Symptoms of arterial TOS are pain, coldness, and a pale discoloration of the hand. Cramps occur when using the arm for activity.

---
